技术特点
Diamond tweeter
Solid body Tweeter-on-Top
Continuum ™ cone FST
Anti-Resonance plug
Biomimetic Suspension
Matrix ™
Aerofoil ™ cone bass units
Flowport
描述
3-way vented-box system
驱动单元
1x ø25mm (1in) diamond dome high-frequency
1x ø150mm (6in) Continuum cone FST midrange
2x ø200mm (8in) Aerofoil cone bass units
频率范围
20Hz to 35kHz
频率响应
28Hz to 28kHz (+/-3dB from reference axis)
灵敏度
90dB (on axis at 2.83Vrms at 1m)
谐波失真
2nd and 3rd harmonics (90dB,1m on axis)
<1% 80Hz – 20kHz
<0.3% 100Hz – 20kHz
